Savaria PL Portable Lift (formally Handicare/Prism P440)
The PL portable ceiling lift is built for true portability, allowing it to be moved easily from room to room or location to location as needed. Its lightweight design is powered by a lithium battery system, providing reliable lifting performance while weighing significantly less than many competing models.
* Savaria Monarch Portable Model M929001, SWL 440 lbs.
* Savaria Monarch Portable Model M929011, SWL 262 lbs.
Videos
Features
Lightweight – only 11 lb (≈ 5 kg)
Lithium-ion battery – up to 80 lifts per charge
Fast 2-hour recharge
Simple, one-touch controls
30% faster lift speed than competitors
SureClip sling attachment
Compatible with Savaria Gantry
Designed for up to 10 years of use
Specifications
Max Safe Working Load: 286 lbs. (130 kg)
Lift Case: Not Specified
Total Weight (Unboxed): 11 lbs. (5 kg)
Dimensions (L / W/ H): Not Specified
Rail Transfer: Manual
Lifting Range: Not Specified
Lifting Speed (Unloaded): 2.2“/s (5.5 cm/s)
Lifting Speed (Loaded): 2“/s (5 cm/s)
Charger Input: 100-240 VAC
Charger Output: 29.4VDC - maximum 1 A
Emergency Lower: Electric
Hand Control: Wired Electric with UP/DOWN buttons; includes power switch that doubles as an emergency stop
In Track Charging: Not Available
Removable from Track: Yes
Duty Cycle: 10% use, 1 minute rest
Batteries: 25.2 V (2500 mAh), approx. 80 lift cycles at 91 kg, 70 cycles at 130 kg
Noise Level: 54 dBA
Lightweight – only 11 lb (≈ 5 kg)
Lithium-ion battery – up to 80 lifts per charge
Fast 2-hour recharge
Simple, one-touch controls
30% faster lift speed than competitors
SureClip sling attachment
Compatible with Savaria Gantry
Designed for up to 10 years of use
Max Safe Working Load: 286 lbs. (130 kg)
Lift Case: Not Specified
Total Weight (Unboxed): 11 lbs. (5 kg)
Dimensions (L / W/ H): Not Specified
Rail Transfer: Manual
Lifting Range: Not Specified
Lifting Speed (Unloaded): 2.2“/s (5.5 cm/s)
Lifting Speed (Loaded): 2“/s (5 cm/s)
Charger Input: 100-240 VAC
Charger Output: 29.4VDC - maximum 1 A
Emergency Lower: Electric
Hand Control: Wired Electric with UP/DOWN buttons; includes power switch that doubles as an emergency stop
In Track Charging: Not Available
Removable from Track: Yes
Duty Cycle: 10% use, 1 minute rest
Batteries: 25.2 V (2500 mAh), approx. 80 lift cycles at 91 kg, 70 cycles at 130 kg
Noise Level: 54 dBA
About
PL Portable lift
The PL portable ceiling lift was designed from the ground up to be a truly portable lift – one that can be easily carried from room to room or place to place when needed. At the heart of the system, a lithium battery system delivers patient lifting power with significantly less product weight than industry competitors.
Whether you are a patient or a caregiver, a Savaria Portable Ceiling Lift provides security for lifting and transferring in a home setting. The lift helps prevent the risk of injury to caregivers, including back strains that are common occurrences with manual lifting. Patients can feel peace of mind and security when moving or transferring using the Savaria lift. For some, a Savaria ceiling lift is the solution for leaving the hospital sooner and recovering in the comfort of their home.
5 kg (11 lb)
10 years with only 1 battery replacement
200 kg (440 lb) or 130 kg (286 lb)
5.5 cm/sec (2.2 in/sec) at 0 kg, 5 cm/sec (2 in/sec) at 130 kg (286 lb), 4.5 cm/sec (1.8 in/sec) at 200 kg (440 lb)
54 dBA
Class 1
3 Years
Whether you use the hand pendant, or the motor unit controls, you will experience an intuitive design for up and down commands. There are no extraneous bells and whistles to create confusion, or break downs.
